Specifications:
| Models | NWA1302-AC 802.11ac Wall-Plate PoE Access Point |
|---|---|
| Wireless | |
| Standard | IEEE802.11 ac/n/g/b/a |
| MIMO | SU-MIMO |
| Peak speed | 2.4GHz: 300Mbps 5GHz: 866Mbps |
| Frequency band | 2.4 GHz (IEEE 802.11 b/g/n)
5 GHz (IEEE 802.11 a/n/ac)
|
| Bandwidth | 20-, 40- and 80-MHz |
| Conducted typical transmit output power | US (2.4GHz/5GHz): 18/19dBm EU (2.4GHz/5GHz): 17/19dBm |
| RF Design | |
| Antenna type | 2×2 MIMO smart antenna |
| Antenna gain | 2.4GHz: 5 dBi 5GHz: 5 dBi |
| Minimum Receive sensitivity | Min. Rx sensitivity up to -98 dBm |
| WLAN feature | |
| Band Steering | Yes |
| WDS | Yes |
| Security | |
| encryption | WEP/ WPA/WPA2-PSK |
| authentication | WPA/WPA2-Enterprise/ EAP/ IEEE 802.1X/ RADIUS authentication |
| Access management | L2-isolation/ MAC filtering |
| networking | |
| IPv6 | Yes |
| VLANs | Yes |
| WMM | Yes |
| Management | |
| Operating mode | Cloud managed / standalone |
| ZON Utility |
|
| ZAC |
|
| Web UI/ CLI | Yes |
| SNMP | Yes |
| Physical Specifications | |
| Item | Dimensions (WxDxH)(mm/in.) 211 x 223 x 39 / 8.31 x 8.78 x 1.54 Weight (g/lb.) 800/1.763 |
| Packing | Dimensions (WxDxH)(mm/in.) 251 x 247 x 55/ 9.88 x 9.72 x 2.17 Weight (g/lb.) 1040/2.292 |
| Included accessories | Multi-purpose mounting bracket with screws |
| MTBF(hr) | 809,263 |
| Ethernet port | 1x 10/100/1000M uplink 3x 10/100/1000M downlink(including on PoE PSE) |
| Power |
|
| Environmental Specifications | |
| Operating | Temperature 0°C to 50°C/32°F to 122°F Humidity 10% to 95% (non-condensing) |
| Storage | Temperature -30°C to 70°C/-22°F to 158°F Humidity 10% to 90% (non-condensing) |
| Certifications | |
| Radio | ETSI EN 300 328, FCC Part 15C, LP0002, EN 60601-1-2 |
| EMC | EN 301 489-1, EN 301 489-17,EN55022, EN55024, EN61000-3-2/-3, FCC Part B, BSMI CNS13438 |
| Safety | EN 60950-1, IEC 60950-1, BSMI CNS14336-1 |
