Specifications:
| Models | NSG50 | NSG100 | NSG200 | NSG300 |
|---|---|---|---|---|
| Models | ||||
| Description | Nebula Cloud Managed Security Gateway | Nebula Cloud Managed Security Gateway | Nebula Cloud Managed Security Gateway | Nebula Cloud Managed Security Gateway |
| Hardware Specifications | ||||
| 10/100/1000 Mbps RJ-45 ports | 4 x LAN (GbE), 2 x WAN (1x SFP, 1x GbE) | 4 x LAN (GbE), 2 x WAN (GbE) | 5 x LAN (GbE), 2 x WAN (GbE) | 6 x Individual LAN (GbE), 2 x WAN (GbE) |
| USB ports | 1 | 2 | 2 | 2 |
| Console port | Yes (RJ-45) | Yes (DB9) | Yes (DB9) | Yes (DB9) |
| Rack-mountable | – | Yes | Yes | Yes |
| Wall-mountable | Yes | – | – | – |
| Fanless | Yes | Yes | – | – |
| System Capacity & Performance *1 | ||||
| SPI firewall throughput (Mbps) *2 | 300 | 450 | 1,250 | 4,000 |
| VPN throughput (Mbps)*3 | 100 | 150 | 500 | 750 |
| IDP throughput (Mbps)*4 | 110 | 160 | 500 | 950 |
| AV throughput (Mbps)*4 | 50 | 90 | 300 | 450 |
| SP throughput (Mbps, AV and IDP)*4 | 50 | 90 | 300 | 450 |
| Unlimited users | Yes | Yes | Yes | Yes |
| Max. TCP concurrent sessions*5 | 20,000 | 40,000 | 80,000 | 500,000 |
| Max. TCP session rate | 2,000 | 2,000 | 8,000 | 10,000 |
| Max. concurrent IPsec VPN tunnels*6 | 10 | 40 | 200 | 300 |
| VLAN interface | 8 | 16 | 16 | 16 |
| Key Software Features | ||||
| Firewall | Yes | Yes | Yes | Yes |
| Virtual private network (VPN) | Yes (IPSec, L2TP over IPSec) | Yes (IPSec, L2TP over IPSec) | Yes (IPSec, L2TP over IPSec) | Yes (IPSec, L2TP over IPSec) |
| Application Patrol | Yes | Yes | Yes | Yes |
| Intrusion Detection and Prevention (IDP) | Yes | Yes | Yes | Yes |
| Bandwidth Management | Yes | Yes | Yes | Yes |
| Content Filtering | Yes | Yes | Yes | Yes |
| Anti-Virus | Yes | Yes | Yes | Yes |
| WAN Failover | Yes | Yes | Yes | Yes |
| Power Requirements | ||||
| Power input | 12 V DC, 2.0 A max. | 12 V DC, 3.0 A max. | 12 V DC, 3.33 A max. | 100 – 240V AC, 50/60 Hz, 1.3 A max. |
| Max. power consumption (watt) | 12 | 19 | 37 | 58.5 |
| Heat dissipation (BTU/hr) | 40.95 | 64.83 | 199.61 | 199.61 |
| Physical Specifications | ||||
| Item | Dimensions (WxDxH)(mm/in.): 216 x 143 x 33/8.50 x 5.63 x 1.30 Weight (kg/lb.): 1.04/2.29 |
Dimensions (WxDxH)(mm/in.): 242 x 175 x 36/9.53 x 6.89 x 1.42 Weight (kg/lb.): 1.25/2.76 |
Dimensions (WxDxH)(mm/in.): 300 x 178 x 44/11.81 x 7.0 x 1.73 Weight (kg/lb.): 2.0/4.4 |
Dimensions (WxDxH)(mm/in.): 430 x 250 x 44/16.93 x 9.84 x 1.73 Weight (kg/lb.): 3.3/7.28 |
| Packing | Dimensions (WxDxH)(mm/in.): 276 x 185 x 98/10.87 x 7.28 x 3.86 Weight (kg/lb.): 1.41/3.11 |
Dimensions (WxDxH)(mm/in.): 394 x 240 x 101/15.51 x 9.45 x 3.98 Weight (kg/lb.): 2.25/4.96 |
Dimensions (WxDxH)(mm/in.): 351 x 243 x 149/13.82 x 9.57 x 5.87 Weight (kg/lb.): 3.264/7.20 |
Dimensions (WxDxH)(mm/in.): 519 x 392 x 163/20.43 x 15.43 x 6.42 Weight (kg/lb.): 4.8/10.58 |
| Included accessories |
|
|
|
|
| Environmental Specifications | ||||
| Operating | Temperature : 0°C to 40°C/32°F to 104°F Humidity: 10% to 90% (non-condensing) |
|||
| Storage | Temperature : -30°C to 70°C/-22°F to 158°F Humidity: 10% to 90% (non-condensing) |
|||
| MTBF (hr) | 44,000.0 | 815,463.9 | 787,109.3 | 560,811.50 |
| Certifications | ||||
| EMC |
|
|
|
|
| Safety |
|
|
||
