Product Specifications
| General | |
|---|---|
| Device Type | Hard drive – internal |
| Capacity | 10 TB |
| Form Factor | 3.5″ x 1/3H |
| Interface | SATA 6Gb/s |
| Buffer Size | 256 MB |
| Bytes per Sector | 512 |
| Features | Temperature sensor, Enterprise Class Reliability, PowerChoice, Humidity Sensor, Low Halogen, Super Parity, Hot-Plug Support, PowerBalance, advanced format 512e, 24×7 availability, Organic Solderability Preservative, Multi-Step Forged Helium Sealed-Drive design, Superior Wide-Weld Hermetically Sealed-Drive enclosure, pressure sensor, Advanced Write Caching |
| Width | 4 in |
| Depth | 5.8 in |
| Height | 1 in |
| Weight | 22.93 oz |
| Performance | |
|---|---|
| Drive Transfer Rate | 600 MBps (external) |
| Internal Data Rate | 249 MBps |
| 4KB Random Read | 170 IOPS |
| 4KB Random Write | 370 IOPS |
| Average Latency | 4.16 ms |
| Spindle Speed | 7200 rpm |
| Reliability | |
|---|---|
| MTBF | 2,500,000 hours |
| 24×7 Operation | Yes |
| Non-Recoverable Errors | 1 per 10^15 |
| Expansion & Connectivity | |
|---|---|
| Interfaces | 1 x SATA 6 Gb/s |
| Compatible Bay | 3.5″ x 1/3H |
| Power | |
|---|---|
| Power Consumption | 4.5 Watt (idle)
8 Watt (write) 8.4 Watt (random read) |
| Manufacturer Warranty | |
|---|---|
| Service & Support | Limited warranty – 5 years |
| Environmental Parameters | |
|---|---|
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 5 – 95% (non-condensing) |
| Shock Tolerance (operating) | 40 g @ 2 ms |
| Shock Tolerance (non-operating) | 250 g @ 1 ms |
| Vibration Tolerance (operating) | 0.5 g @ 22-350 Hz |
| Vibration Tolerance (non-operating) | 2.27 g @ 10-500 Hz |
