- Display parameters
- Size/
- Operation method/
- Type/
- Video parameters
- Supplement light
IR supplement
- Lens1
- FOVHorizontal: 129° Vertical: 75°
- Pixel
Main stream: 1920 × 1080p, 720p
Sub stream: 704 × 576
- Audio parameters
- Audio qualityNoise suppression and echo cancellation
- Network parameters
- Communication protocol
TCP/IP, RTSP
- Wired network10/100 Mbps self-adaptive Ethernet
- Wi-Fi/
- Bluetooth/
- Device interfaces
- Network interface1
- Exit button1
- Lock control1
- Door contact input1
- Power interface1
- General
- Button1
- InstallationSurface mounting
- Indicator2
- 190g
- Protective levelIP65
- Power supply method
IEEE802.3af, standard PoE
12 VDC
- Working temperature-40° C to +55° C(-40° F to 131° F)
- Working humidity10% to 95%
- Dimensions138 mm × 65 mm × 27 mm
- Battery/
- Application environmentOutdoor
- Power consumption＜ 10 W
