Specifications
| Model | fi-7160 | ||
|---|---|---|---|
| Functional Specifications | |||
| Image Sensor Type | Color CCDs (Color Charge Coupled Device) | ||
| Light Source | White LED Array | ||
| Optical Resolution | 600 dpi | ||
| Output Resolution(1) | Color (24-bit) | 50 to 600 dpi (adjustable by 1 dpi increments, 1,200 dpi(2)) |
|
| Grayscale (8-bit) | |||
| Monochrome | |||
| Output Color Depth | Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit | ||
| Internal Video Processing | 1,024 levels (10-bit) | ||
| Image Processing Function | |||
| Hardware | Dropout color (Red / Green / Blue), Deskew cropping | ||
| Software | Multi-image, Blank page skip, i-DTC, Advanced-DTC, Simplified-DTC, sRGB, Auto color, Deskew cropping, Hole Punch removal, Tab cropping, Upper lower separation, Error diffusion, Dither, Moire removal, Image Emphasis, Color cleanup, Dropout color (R,G,B, None, white,Specified, Color Saturation), Edge repair, Vertical Streaks Reduction | ||
| Scanning Speed(3) (A4, Portrait) |
Color(4) Grayscale(4) Monochrome(5) |
ADF | Simplex: 60 ppm, Duplex: 120 ipm (200 dpi / 300 dpi) |
| ADF Capacity(6) | 80 Sheets (A4: 80 g/m² or 20 lb.) | ||
| Daily Duty Cycle | 4,000 Pages | ||
| Document Size | ADF Minimum | 50.8 mm x 54 mm (2 in. x 2.13 in.) (Landscape / Portrait) | |
| ADF Maximum(7) | 216 mm x 355.6 mm (8.5 in. x 14 in.) | ||
| Long Document | 216 mm x 5,588 mm (8.5 in. x 220 in.)(18.3 ft.)(8) | ||
| ADF Feeding Paper Weight (Thickness) |
Letter | 27 g/m² to 413 g/m² (7.2 lb. to 110 lb.) | |
| A8 Sheets | 127 g/m² to 209 g/m² (34 lb. to 56 lb.) | ||
| Card(9) | Up to 1.4 mm portrait and landscape feeding(10) | ||
| Interface(11) | USB 3.0 / USB 2.0 / USB 1.1 (backward compatible) | ||
| Minimum PC Specification | PaperStream IP i5 2.5 MHz Processor, 4 GB RAM | ||
| Physical Specifications | |||
| Power Requirements | 100 to 240 VAC ±10 % | ||
| Power Consumption | Operating mode: 38 W or less, Sleep mode: 1.8 W or less, Auto Standby(Off) mode: 0.35 W or less | ||
| Dimensions (WxDxH)(12) | 300 mm x 170 mm x 163 mm (11.8 in. x 6.7 in. x 6.4 in.) | ||
| Weight | 4.2 kg (9.26 lb.) or less | ||
| Environmental Compatibility | ENERGY STAR® / RoHS | ||
| Operating Environment | Temperature | 5 to 35°C (41 to 95°F) | |
| Relative Humidity | 20 % – 80 % (non-condensing) | ||
| Inbox Contents | ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM, Getting Started Guide |
||
| Bundled Software | PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver(13), PaperStream Capture, ScanSnap Manager for fi Series(14), Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap™(14), Scanner Central Admin | ||
| Options | 2D Barcode for PaperStream, Post-scan Imprinter, Carrier Sheet, PaperStream Capture Pro | ||
| OS Support | Windows® 10 (32-bit/64-bit), Windows® 8.1 (32-bit/64-bit), Windows® 7 (32-bit/64-bit), Windows Server® 2019 (64-bit), Windows Server® 2016 (64-bit), Windows Server® 2012 R2 (64-bit), Windows Server® 2012 (64-bit), Windows Server® 2008 R2 (64-bit), Windows Server® 2008 (32-bit/64-bit), macOS (64-bit)(13)(14), Linux (Ubuntu)(13)(14) | ||
| Feed Detection Features | Ultrasonic Double Feed Detection Sensor, iSOP (Intelligent Sonic Paaper Protection), Intelligent Multi-Feed Function (Manual Bypass) |
||
| Other Features | Embossed Card Scanning Capability, Long Document Scanning, Scanner Central Admin management, USB 3.0 Support, iSOP (Intelligent Sonic Paper Protection), Automatic: Color Recognition, Paper-Size Detection, De-skew Correction |
||
- Maximum output resolutions may vary, depending upon the size of the area being scanned.
- Some limitations may apply to the size of documents that can be scanned, depending on system environment, when scanning at high resolution (over 600 dpi).
- Actual scanning speeds are affected by data transmission and software processing times.
- Indicated speeds are from using JPEG compression.
- Indicated speeds are from using TIFF CCITT Group 4 compression.
- Maximum capacity depends on paper weight and may vary.
- Document sizes larger than A4, but not exceeding A3, can be scanned (single-side) using an optional carrier sheet.
- The scanning of documents that exceed 34 inches in length will be limited to using PaperStream IP at 200 dpi or less. 300 dpi is 215 inches.
- Supports ISO7810 embossed cards.
- Capable of scanning up to 3 cards at a time. (Note: does not support multi-embossed card feeding.)
- Connection with USB3.0 / 2.0 requires the USB port and the hub to support USB3.0 / 2.0. Also note that the scanning speed slows down when using USB1.1.
- Excluding the ADF paper chute and stacker
- Functions equivalent to those offered by PaperStream IP may not be available with the WIA Driver.
- Software can be downloaded from the website designated in the Setup DVD-ROM.
- Availability of support may vary depending on region. Some functions may not be available with the Image Scanner Driver for Linux.
