Specifications
| Description | fi-7140 | ||
|---|---|---|---|
| Supported operating systems | Windows® 10 (32-bit/64-bit), Windows® 8.1 (32-bit/64-bit), Windows® 7 (32-bit/64-bit), Windows Server® 2019 (64-bit), Windows Server® 2016 (64-bit), Windows Server® 2012 R2 (64-bit), Windows Server® 2012 (64-bit), Windows Server® 2008 R2 (64-bit), Windows Server® 2008 (32-bit/64-bit), macOS (64-bit)(1)(2), Linux (Ubuntu)(1)(2) | ||
| Sensor type | Automatic Document Feeder (ADF) | ||
| Scanning modes | Simplex / Duplex, Color / Grayscale / Monochrome | ||
| Image sensor type | Color CCD (Charge-coupled device) x 2 (front x 1, back x 1) | ||
| Light source | White LED Array x 2 (front x 1, back x 1) | ||
| Multifeed detection | Ultrasonic multi-feed detection sensor x 1, Paper detection sensor | ||
| Document size | Maximum | 216 x 355.6 mm (8.5 x 14 in.) | |
| Minimum(3) | 50.8 x 54 mm (2 x 2.13 in.) (Landscape / Portrait) | ||
| Long paper scanning(4) | 216 x 5,588 mm (8.5 x 220 in.) | ||
| Paper weight(5) (Thickness) |
Paper | 27 to 413 g/m² (7.2 to 112 lb.) *A8 size: 127 to 209 g/m² (34 to 56 lb.) |
|
| Plastic Card | 1.4 mm or less(6) | ||
| Scanning speed(7) (A4, Portrait) |
Color(8) | Simplex: 40 ppm, Duplex: 80 ipm (200 / 300 dpi) |
|
| Grayscale(8) | |||
| Monochrome(9) | |||
| Paper chute capacity (A4 Portrait)(10) |
80 Sheets ( A4: 80 g/m² or 20 lb. ) | ||
| Daily Duty Cycle | 6,000 Sheets | ||
| Background colors | White / Black (Selectable) | ||
| Optical resolution | 600 dpi | ||
| Output resolution(11) | Color (24-bit) | 50 to 600 dpi (adjustable by 1 dpi increments), 1200 dpi (driver)(12) |
|
| Grayscale (8-bit) | |||
| Monochrome (1-bit) | |||
| Output format | Color | 24-bit | |
| Grayscale | 8-bit | ||
| Monochrome | 1-bit | ||
| Internal video processing | 1,024 levels (10-bit) | ||
| Interface | USB 2.0 / USB 1.1 | ||
| Connector shape | B type | ||
| Image processing functions | Multi image output, Automatic color detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Halftone, De-Screen, Emphasis, Color cleanup, Dropout color (None / Red / Green / Blue / Saturation), sRGB output, Hole punch removal, Index tab cropping, Split image, De-Skew, Edge correction, Vertical streaks reduction, Automatic page size detection | ||
| Power requirements | AC 100 to 240 V ±10% | ||
| Power consumption | Operating: 36 W or less Sleep mode: 1.8 W or less Auto standby (OFF) mode: 0.35 W or less |
||
| Operating environment | Temperature: 5 to 35 °C (41 to 95 °F) Relative humidity: 20 to 80% (Non-condensing) |
||
| Dimensions: Width x Depth x Height(13) | 300 x 170 x 163 mm (11.81 x 6.69 x 6.42 in.) | ||
| Weight | 4.2 kg (9.26 lb.) | ||
| Included software / drivers | PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver(1), PaperStream Capture, ScanSnap Manager for fi Series(2), Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap™(2), Scanner Central Admin | ||
| Environmental compliance | ENERGY STAR® / RoHS | ||
| Included items | ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM | ||
- Functions equivalent to those offered by PaperStream IP may not be available with the Image Scanner Driver for macOS/Linux and WIA Driver.
- Refer to the fi Series Support Site for driver/software downloads and full lineup of all supported operating system versions.
- The minimum scanning area only applies to using the ADF.
- Capable of scanning documents that exceed Legal sheets in length. Long page scanning supports documents with a length of up to 5,588 mm (220 in.) when the resolution is set to 200 dpi or less.
- The paper weight only applies to using the ADF.
- Capable of scanning up to 3 cards at a time. (Note: does not support multi-embossed card feedability.)
- Actual scanning speeds are affected by data transmission and software processing times.
- Indicated speeds are from using JPEG compression.
- Indicated speeds are from using TIFF G4 compression.
- Maximum capacity depends on paper weight and may vary.
- Selectable maximum density may vary depending on the length of scanned document.
- Some limitations may apply to the size of documents that can be scanned, depending on system environment, when scanning at high resolution (over 600 dpi).
- Excluding the ADF paper chute and Stacker.
