GENERAL
Phase
| Single Phase |
UPS Topology
| Line-interactive |
INPUT
Generator Compatibility
| Yes |
Nominal Input Voltage ( Vac )
| 230 ± 10% |
Input Voltage Range ( Vac )
| 165 ~ 290 |
Input Frequency ( Hz )
| 50 ± 5 |
| 60 ± 5 |
Input Frequency Detection
| Auto-sensing |
Rated Input Current ( A )
| 4.55 |
Input Connector Type
| NEMA 5-15P |
Power Cord Length (ft.)
| 4 |
Power Cord Length (m.)
| 1.2 |
OUTPUT
Capacity (VA)
| 1000 |
Capacity (Watts)
| 600 |
On Battery Waveform
| Simulated Sine Wave |
On Battery Voltage(s) ( Vac )
| 230 ± 10% |
On Battery Frequency ( Hz )
| 50 ± 1% |
| 60 ± 1% |
Automatic Voltage Regulation (AVR)
| Single Boost, Single Buck |
Overload Protection
| Circuit Breaker |
Outlet(s) – Total
| 4 |
Outlet Type
| AS x 4 |
Outlet(s) – Battery & Surge Protected
| 4 |
Typical Transfer Time ( ms )
| 4 |
BATTERY
Runtime at 60W ( min )
| 65 |
Runtime at 90W ( min )
| 43 |
Runtime at 200W ( min )
| 14 |
Typical Recharge Time ( Hours )
| 8 |
Start On Battery
| Yes |
User-replaceable
| No |
Battery Type
| Sealed Lead-acid |
SURGE PROTECTION & FILTERING
Surge Suppression ( Joules )
| 125 |
EMI/RFI Filtration
| Yes |
MANAGEMENT & COMMUNICATIONS
LED Indicators
| Power On , Line Mode , Battery Mode , Low Battery |
Audible Alarms
| Battery Mode , Low Battery , Overload , UPS Fault |
PHYSICAL
Form Factor
| Tower |
Enclosure Construction
| Plastic |
Color
| Black |
PHYSICAL SIZE – UPS MODULE
Dimensions (WxHxD) (in.)
| 3.94 x 7.44 x 12.80 |
Dimensions (WxHxD) (mm.)
| 100 x 189 x 325 |
Weight (lbs.)
| 14.77 |
Weight (kg.)
| 6.7 |
ENVIRONMENTAL
Operating Temperature (°F)
| 32 ~ 104 |
Operating Temperature (°C)
| 0 ~ 40 |
Operating Relative Humidity (Non-condensing) ( % )
| 0 ~ 90 |
Operating Elevation ( feet/meters )
| 0-10,000 feet (0-3,000 meters) |
Storage Temperature (°F)
| -4 ~ 122 |
Storage Temperature (°C)
| -20 ~ 50 |
Storage Relative Humidity (Non-condensing) ( % )
| 0 ~ 90 |
Storage Elevation ( feet/meters )
| 0-10,000 feet (0-3,000 meters) |
Online Thermal Dissipation ( BTU/hr )
| 45 |
Audible Noise at 1.5M from Surface of Unit ( dBA )
| 40 |
CERTIFICATIONS
RoHS
| Yes |
WARRANTY
Product Warranty Period (Year)
| 3 |
Battery Warranty Period (Year)
| 1 |
