GENERAL
Phase
| Single Phase |
Capacity (VA)
| 1000 |
Capacity (Watts)
| 700 |
INPUT
Generator Compatibility
| Yes |
Nominal Input Voltage ( Vac )
| 220 |
| 230 |
| 240 |
Input Voltage Range ( Vac )
| 140 ~ 270 Vac |
Input Frequency ( Hz )
| 50 ± 5 |
| 60 ± 5 |
Input Frequency Detection
| Auto-sensing |
Input Connector Type
| IEC C13 | |
DC Input Voltage ( Vdc )
| 12 |
OUTPUT
Output Waveform
| 40%-100% Load, Simulated Sine Wave |
| 0%-40% Load, Pure Sine Wave |
Output Voltage(s) ( Vac )
| 220 ± 5% |
| 230 ± 5% |
| 240 ± 5% |
Output Voltage Setting
| Configurable |
Output Frequency ( Hz )
| 50 ± 1% |
| 60 ± 1% |
Automatic Voltage Regulation (AVR)
| Double Boost, Single Buck |
Overload Protection (On Utility)
| Circuit Breaker |
Overload Protection (On Battery)
| Internal Current Limiting |
Manual Switch
| Bypass Only |
Outlet(s) – Total
| 2 |
Outlet Type
| AS x 2 | |
Auto-charge
| Yes |
Typical Transfer Time ( ms )
| 10 |
SURGE PROTECTION & FILTERING
Lightning / Surge Protection
| Yes |
MANAGEMENT & COMMUNICATIONS
LCD Panel
| Yes |
LCD Information Display
| Operation Type , Power Status , Battery Status , Load Status , Other Information , Event & Log |
LCD Setting & Control
| Alarm Setting , Input & Output , Battery Setting |
LED Indicators
| Power On , Wiring Fault |
Audible Alarms
| Battery Mode , Low Battery , Overload , Overcharge , Overheat |
PHYSICAL
Form Factor
| Tower |
Enclosure Construction
| Metal |
Color
| Yellow |
PHYSICAL SIZE
Dimensions (WxHxD) (mm.)
| 153 x 241 x 208 |
Weight (kg.)
| 9.4 |
SHIPPING DIMENSIONS
Dimensions (WxHxD) (mm.)
| 242 x 346 x 300 |
Weight (kg.)
| 10.5 |
ENVIRONMENTAL
Operating Temperature (°C)
| 0 ~ 40 |
Operating Relative Humidity (Non-condensing) ( % )
| 0 ~ 95 |
Operating Elevation ( feet/meters )
| 0-10,000 feet (0-3,000 meters) |
Storage Temperature (°C)
| -5 ~ 45 |
Storage Relative Humidity (Non-condensing) ( % )
| 0 ~ 95 |
Storage Elevation ( feet/meters )
| 0-50,000 feet (0-15,000 meters) |
CERTIFICATIONS
Certifications
| CE , EAC , SONCAP |
RoHS
| Yes |
EXTERNAL BATTERY (OPTIONAL)
Battery Type
| Sealed Lead-acid |
Battery Voltage ( Vdc )
| 12 |
WARRANTY
Product Warranty Period (Year)
| 2 |
