General
Phase
| Single Phase |
Capacity (VA)
| 3500 |
Capacity (Watts)
| 2450 |
Input
Generator Compatibility
| Yes |
Nominal Input Voltage ( Vac )
| 230 |
| 230 |
| 240 |
Input Voltage Range ( Vac )
| 140 ~ 300 Vac |
Input Frequency ( Hz )
| 50 ± 5 |
| 60 ± 5 |
Input Frequency Detection
| Auto-sensing |
Input Connector Type
| Hardwire Terminal Block |
DC Input Voltage ( Vdc )
| 24 |
Output
Output Waveform
| Pure Sine Wave |
Output Voltage(s) ( Vac )
| 220 ± 5% |
| 230 ± 5% |
| 240 ± 5% |
Output Voltage Setting
| Configurable |
Output Frequency ( Hz )
| 50 ± 1% |
| 60 ± 1% |
Automatic Voltage Regulation (AVR)
| Single Boost, Single Buck |
Overload Protection (On Utility)
| Circuit Breaker |
Overload Protection (On Battery)
| Internal Current Limiting |
Manual Switch
| Normal, Bypass with AVR, Bypass, Off |
Outlet(s) – Total
| 3 |
Outlet Type
| Hardwire Terminal Block x 1 | |
| Schuko x 2 | |
Auto-charge
| Yes |
Typical Transfer Time ( ms )
| 10 |
Surge Protection & Filtering
Lightning / Surge Protection
| Yes |
Management & Communications
LCD Panel
| Yes |
LCD Information Display
| Operation Type, Power Status, Battery Status, Load Status, Other Information, Event & Log |
LCD Setting & Control
| Alarm Setting, Input & Output, Battery Setting |
LED Indicators
| Power On, Wiring Fault |
Audible Alarms
| Battery Mode, Low Battery, Overload, Overcharge, Overheat |
Power Management Software
| PowerPanel® Business (Recommended) |
SNMP / HTTP Remote Monitoring
| Yes – with optional RMCARD205 |
Physical
Form Factor
| Tower |
Enclosure Construction
| Metal |
Color
| Yellow |
Wheels
| Yes |
Physical Size
Dimensions (WxHxD) (mm.)
| 260 x 440 x 330 |
Weight (kg.)
| 36.53 |
Shipping Dimensions
Dimensions (WxHxD) (mm.)
| 370 x 555 x 445 |
Weight (kg.)
| 38.75 |
Environmental
Operating Temperature (°C)
| 0 ~ 40 |
Operating Relative Humidity (Non-condensing) ( % )
| 0 ~ 95 |
Operating Elevation ( feet/meters )
| 0-9,843 feet (0-3,000 meters) |
Storage Temperature (°C)
| -15 ~ 45 |
Storage Relative Humidity (Non-condensing) ( % )
| 0 ~ 95 |
Storage Elevation ( feet/meters )
| 0-49,213 feet (0-15,000 meters) |
Certifications
Certifications
| CE, EAC, SONCAP |
RoHS
| Yes |
External Battery (Optional)
Battery Type
| Sealed Lead-acid |
Battery Voltage ( Vdc )
| 24 |
